Onshore 3D seismic acquisition in Suriname for Staatsolie

Working as project advisors and as part of the project team, RPS supported Staatsolie, the state-owned oil company of Suriname, to define, design and deliver a high-resolution onshore seismic survey.

Staatsolie's objective was to acquire the data to develop a more accurate subsurface model to aid in the identification of new reserves and improve their reservoir's production performance. To ensure this acquisition project went off without a hitch, RPS provided field survey project management, in-field quality assurance and quality control (QA/QC) and post-survey seismic processing expertise.

48,338
seismic records
451
Crew size
45.5km2
survey area
172
days of seismic recording

The area for the survey is made of erratically deposited fluvial to deltaic reservoirs. An accurate subsurface model contributes significantly to the success rates and production potential. The model also aids in the identification of new reserves, improves the understanding of the reservoirs' production performance, contributes to the implementation of EOR projects and is integral in the development of an optimal depletion plan.

The challenge was to collect data which would improve the structural image and stratigraphic resolution of the onshore Paleocene and Eocene sands to develop the remaining reserve potential further. The targets were shallow and included thin reservoirs, narrow channel complexes, compartmentalization: pinch outs and faults.  To achieve these objectives, RPS seismic survey specialist designed a high-resolution seismic survey which exceeded anything else acquired onshore Suriname to date.

The project included a survey design phase followed by the collection of a test line to evaluate a range of seismic sources and receivers to maximize seismic frequencies and signal levels. The test proved the best explosive charge size and depth and that vertical hydrophones at specific depths generated substantial uplift in frequencies.

To ensure the project's success at every stage, RPS field survey project managers were used to identify and manage project risks, while keeping the project on track. RPS' infield QA/QC specialists oversaw the acquisition process to ensure the data being recorded was meeting the project's specifications. Seismic specialists at RPS supported Staatsolie during the field and in the post-field data processing.

The project is on track to provide a subsurface model that aids in making informed decisions on where to drill, how to improve existing wells and plan for well depletion, with increased confidence.



Services

  • Seismic survey design
  • Field project management
  • Seismic quality control and quality assurance
  • Processing quality control and quality assurance
